Corrugated Flat Duct: Space-Optimized Airflow Engineering‌
‌Application Scenarios
Ideal for constrained spaces where traditional ducts fail:
- ‌Residential‌: HVAC retrofits (fits within 2″ wall cavities).
- ‌Commercial‌: Kitchen exhausts (UL 181 fire-rated), server room cooling.
- ‌Industrial‌: Confined machinery ventilation (chemical-resistant PVC variants).
‌
Engineering Solutions‌
- ‌Low-Profile Design‌: 10–30 mm height, 100–300 mm width ranges (DW/144 compliant).
- ‌Quick-Connect Systems‌: Compression fittings reduce labor time by 50% vs. rigid ducts.
‌Advanced Technical Parameters‌
- ‌Airflow Performance‌: 0.5–1.8 m/s velocity, ΔP ≤15 Pa/m (AMCA 210-tested).
- ‌Material Options‌: Aluminum (0.1–0.3 mm) or PVC (1.5–3.0 mm thickness).
‌Smart Function Expansion‌
- ‌IoT-Ready‌: Optional embedded airflow sensors (0–10 V output for BMS integration).
- ‌Acoustic Lining‌: Hybrid designs achieve 35 dB(A) @ 3 m (ISO 3744).
‌Technical Notes‌
- ‌Bend Radius‌: Minimum 3× duct width without kinking (per SMACNA guidelines).
- ‌Leakage Class‌: ≤5% @ 250 Pa (EN 12237 validated).
‌Why Choose Us?‌
- ‌Certified‌: UL 181, Eurovent 6/1, and LEED v4.1 compliant.
- ‌Global Stock‌: 48-hour dispatch with CAD/BIM support.
